GS212 is linear bearing scale based on optical principle. It offers resolutions down to 0.1µ, with repeat accuracy of one count. It possesses IP54 rating. This compact design helps in easy mounting in congested spaces. Offering lengths from 70mm upto even 3m (customised lengths possible), this scale is a preferred choice for high accuracy machining and metrology applications.
| Feature | Details |
|---|---|
| Resolution | 0.1 / 0.5 / 1 / 5 / 10 µm |
| Grating Pitch | 40 µm |
| Accuracy Class | ± 5 / ± 10 / ± 20 µm |
| Resolution | ± 1 Resolution Count |
| Measuring Lengths (mm) | 70, 120, 170, 220, 270, 320, 370, 420, 470, 520, 620, 720, 770, 820, 920, 1020, 1120, 1240, 1340, 1440, 1540, 1640, 1740, 1840, 1940, 2040 or more... Customised length available on request |
| Current Consumption | Typ. 150mA (250mA max) |
| Power Supply | + 5 VDC (± 5%) |
| Output Signal | RS422, 11µA, 1 Vp-p |
| Reference Mark | At 15mm from start then after every 25mm/50mm |
| Operating Temperature | 10oC to +50oC |
| Storage Temperature | -20oC to +70oC |
| Relative Humidity | 20% to 80% Non-condensing |
| Standard Cable Length | 3 meter up to 820mm armoured or non-armoured 5 meter above 820mm armoured or non-armoured or |
| Max. Cable Length | 20 meters |
| Measurement Speed | 2 m/s at 1µm and above resolutions 0.5 m/s below 1µm resolutions |
| Protection Class | IP54 |
Mechanical Drawings:
